Does This Tank Stand Diagram Look Sturdy?

[Brian085]

I made a quick sketchup of a 55 gallon tank stand I would like to construct. I would be using 2x4's for the frame then thinner wood on the outside which would be stained to look nice. So I was wondering if anyone who might have past experience on doing this could give some constructive comments on my project. Thank you for any comments and thoughts.



[rdd1952]

Not being an engineer, I wouldn't say for sure but I would be a little concerned with a single 2x4 under the front and back center.



[mixmaster jay]

haven't you allready posted this up tolack and me have comented on that one lol

its all fine but i would put 2 crossbeams under the tank base mate



[Brian085]

Im not sure why two were posted. I planned on having a 2x4 on the bottom in the middle and on top in the middle going across.



[raptorrex]

it looks ok to me. however i would add bars to stop any lateral movement of the tank, also.



[Brian085]

When you say add bars to stop the movement you mean have something stick up on the sides of the stand around the bottom?



[Truck]

the joins could use some work...some good old fashioned mortise joints will make it more rigid



[raptorrex]

When you say add bars to stop the movement you mean have something stick up on the sides of the stand around the bottom?

well, more like this:

bit rough, but you get my drift.
